Olympus CV‑290 • CLV‑290 Electronic Endoscope Image Processor
-
Estimated Delivery:Oct 13 - Oct 17
-
Free Shipping & Returns: On all orders over $75
This endoscope light source system consists of the Olympus CV‑290 processor and Olympus CLV‑290 endoscope light source unit.
CV‑290:NBI (Narrow‑Band Imaging) for EVIS LUCERA ELITE delivers twice the viewing distance of EVIS LUCERA SPECTRUM. Advanced noise reduction performs more effectively, and image response speed from dark to bright conditions is improved.
When connected to HQ‑series endoscopes, the CV‑290 integrates required electronics to activate the dual‑focus function, delivering comfortable viewing angles for both near‑field and far‑field observation.
The newly‑designed waterproof one‑touch connector enables one‑step connection with the light source. No separate endoscope cable is needed for the image‑processing unit.
Newly‑optimized image processing delivers sophisticated image quality with enhanced color reproduction. Excellent imaging performance is achieved through the matched combination of endoscope and system.
Compatible with EVIS 200/230/240 series, EVIS LUCERA 260 series and EVIS LUCERA ELITE 290 series endoscopes.
16:9 and 16:10 HDTV monitor outputs are available. Analog, HD‑SDI and DVI outputs are supported.
Simplified peripheral‑device connection eliminates complicated cabling and accelerates data transmission speed.
The Olympus file system enhances network expandability.
Picture‑in‑picture and index functions effectively improve observation efficiency.
Compatible with portable memory devices for standard‑compliant data management; simply connect and upload data.
Supports DV output to compatible documentation devices.
CV290‑CLS:Voltage: 100‑240 VACFrequency: 50/60 HzPower consumption: 600 VADimensions: 370 × 150 × 476 mm (standard); 390 × 162 × 551 mm (maximum)Weight: 18 kg
